BT C3E200 Forklift

BT C3E200 Forklift Specs front
BT C3E200 Forklift Specs front
BT C3E200 Forklift Specs side
BT C3E200 Forklift Specs side
BT C3E200 Forklift Specs back
BT C3E200 Forklift Specs back
Units

Dimensions

Dimensions

A

Length to Fork Face

7.1 ft in

B

Overall Width

3.31 ft in

C

Overall Height - mast lowered

6.76 ft in

D

Wheelbase

5.06 ft in

E

Ground Clearance

3.55 in

F

Height to Top of Overhead Guard

6.4 ft in

G

Max Fork Height

9.75 ft in

MAST

H

Mast Tip Forward

2.3 degrees

I

Mast Tip Rear

6 degrees


Specifications

Engine

Power

16.1 hp

Fuel Type

electric

Operational

Operating Weight

7859.5 lb

Tire Type

front 200/50-10 rear 16x6-8

Number of Front Wheels

2

Number of Rear Wheels

2

Max Speed

9.1 mph

MAST

Load Capacity

4409.3 lb

Load Center

19.7 in

Mast Tip Forward

2.3 degrees

Mast Tip Rear

6 degrees

Lift Speed

118.2 ft/min

Lower Speed

98.5 ft/min

Dimensions

Wheelbase

5.1 ft in

Length to Fork Face

7.1 ft in

Overall Width

3.4 ft in

Overall Height - mast lowered

6.8 ft in

Max Fork Height

9.8 ft in

Turning Radius

6 ft in

Height to Top of Overhead Guard

6.4 ft in

Ground Clearance

3.6 in


Compare similar models

Manufacturer / Model

Power

Operating Weight

Load Capacity

Power

16.1 hp

Operating Weight

7760.3 lb

Load Capacity

4409.3 lb

Power

15.5 hp

Operating Weight

8377.6 lb

Load Capacity

4409.3 lb

Power

15.5 hp

Operating Weight

8377.6 lb

Load Capacity

4409.3 lb
