Bomag BW177D3 Vibratory Smooth Drum Roller

Bomag BW177D3 Vibratory Smooth Drum Roller Specs front
Bomag BW177D3 Vibratory Smooth Drum Roller Specs front
Bomag BW177D3 Vibratory Smooth Drum Roller Specs side
Bomag BW177D3 Vibratory Smooth Drum Roller Specs side
Bomag BW177D3 Vibratory Smooth Drum Roller Specs back
Bomag BW177D3 Vibratory Smooth Drum Roller Specs back
Units

Dimensions

Dimensions

A

Overall Length

15.3 in

C

Height to Top of Cab

9.31 ft in

D

Wheelbase

8.18 in

E

Ground Clearance

13.94 in

F

Drum Diameter - Front

4.03 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2347

Engine Model

B4.5-80C

Gross Power

80.5 hp

Net Power

77.8 hp

Power Measured @

2200 rpm

Operational

Operating Weight

15939.5 lb

Fuel Capacity

33.1 gal

Max Speed

6.3 mph

Tires *if applicable

14.9-24-AWT 6PR

Operating Voltage

12 V

Drum

Drum Width

66.4 in

Drum Diameter

48.4 in

Static Linear Load

325.8 lb/in

Vibration Frequency 1

30 Hz

Nominal Amplitude - High

0.1 in

Centrifugal Force - High

30349.3 lb

Vibration Frequency 2

40 Hz

Nominal Amplitude - Low

0.1 in

Centrifugal Force - Low

26977.1 lb

Dimensions

Wheelbase

8.2 in

Overall Length

15.3 in

Height to Top of Cab

9.4 ft in

Ground Clearance

14 in

Drum Diameter - Front

4.1 ft in


Compare similar models

Manufacturer / Model

Net Power

Operating Weight

Drum Width

Net Power

79.2 hp

Operating Weight

15410.4 lb

Drum Width

67 in

Net Power

74.3 hp

Operating Weight

16755.2 lb

Drum Width

66.2 in

Net Power

79.2 hp

Operating Weight

16689 lb

Drum Width

59.1 in
