Bobcat2000 (1983-1987)Wheel Loader

Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Units

Dimensions

Dimensions

A

Length with Bucket on Ground

13.59ft in

C

Height to Top of Cab

7.77ft in

D

Wheelbase

4.83ft in

E

Ground Clearance

0.67ft in

F

Hinge Pin - Max Height

10.17ft in

H

Reach at Max Lift and Dump

2.11ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2351

Engine Model

4.154 (200 Series)

Net Power

54hp

Power Measured @

2600rpm

Displacement

153.9cu in

Operational

Operating Weight

7625lb

Static Tipping Weight

1800lb

Tire Size

10.0x16.5

Transmission

Transmission Type

hydrostatic

Max Speed - Forward

10mph

Max Speed - Reverse

5mph

Hydraulic System

Relief Valve Setting

2450

Pump Flow Capacity

21.5gal/min

Bucket

Bucket Width

5.6ft in

Dimensions

Length with Bucket on Ground

13.6ft in

Height to Top of Cab

7.8ft in

Ground Clearance

0.7ft in

Wheelbase

4.9ft in

Hinge Pin - Max Height

10.2ft in

Reach at Max Lift and Dump

2.2ft in
