Bell HD1023 Mark 3 Hydraulic Excavator

Bell HD1023 Mark 3 Hydraulic Excavator Specs front
Bell HD1023 Mark 3 Hydraulic Excavator Specs front
Bell HD1023 Mark 3 Hydraulic Excavator Specs side
Bell HD1023 Mark 3 Hydraulic Excavator Specs side
Bell HD1023 Mark 3 Hydraulic Excavator Specs extended
Bell HD1023 Mark 3 Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

I

Max Cutting Height

16.74 ft in

J

Max Loading Height

21.49 ft in

K

Max Reach Along Ground

30.84 ft in

M

Max Digging Depth

19.53 ft in

Dimensions

B

Width to Outside of Tracks

9.81 ft in

D

Length of Track on Ground

11.36 ft in

E

Ground Clearance

1.58 ft in

H

Tail Swing Radius

9.65 ft in

Undercarriage

N

Shoe Size

23.63 in


Specifications

Engine

Engine Make

2251

Engine Model

C 6D34-TLE2A

Gross Power

167.7 hp

Operational

Operating Weight

51963 lb

Hydraulic System Relief Valve Pressure

4771.8 psi

Hydraulic Pump Flow Capacity

130.6 gal/min

Undercarriage

Shoe Size

23.7 in

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

standard

Max Digging Depth

19.6 ft in

Max Reach Along Ground

30.9 ft in

Max Cutting Height

16.8 ft in

Max Loading Height

21.5 ft in

Dimensions

Width to Outside of Tracks

9.9 ft in

Ground Clearance

1.6 ft in

Tail Swing Radius

9.7 ft in

Length of Track on Ground

11.4 ft in
