Astra ADT25C Articulated Dump Truck

Astra ADT25C Articulated Dump Truck Specs front
Astra ADT25C Articulated Dump Truck Specs front
Astra ADT25C Articulated Dump Truck Specs side
Astra ADT25C Articulated Dump Truck Specs side
Astra ADT25C Articulated Dump Truck Specs back
Astra ADT25C Articulated Dump Truck Specs back
Units

Dimensions

Dimensions

A

Overall Length

32.92 ft in

B

Overall Width

9.72 ft in

C

Overall Height

12.22 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2358

Engine Model

Cursor 10

Gross Power

315.2 hp

Power Measured @

2100 rpm

Displacement

628.6 cu in

Max Torque

1069.5 lb ft

Torque Measured @

1000 rpm

Operational

Tire Size

23.5R25

Transmission

Number of Forward Gears

6

Number of Reverse Gears

3

Max Speed

29 mph

Weights

Total Empty

49030.9 lb

Dump

Rated Payload

51147.3 lb

Capacity - Heaped

19 yd3

Raise Time

13 sec

Lower Time

13 sec

Dimensions

Overall Length

33 ft in

Overall Width

9.8 ft in

Overall Height

12.3 ft in
