Airman AX50U-4 Midi Excavator

Airman AX50U-4 Midi Excavator Specs front
Airman AX50U-4 Midi Excavator Specs front
Airman AX50U-4 Midi Excavator Specs side
Airman AX50U-4 Midi Excavator Specs side
Airman AX50U-4 Midi Excavator Specs extended
Airman AX50U-4 Midi Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

17.92 ft in

C

Shipping Height of Unit

8.37 ft in

J

Max Loading Height

13.46 ft in

K

Max Reach Along Ground

19.69 ft in

L

Max Vertical Wall Digging Depth

9.36 ft in

M

Max Digging Depth

11.82 ft in

Dimensions

B

Width to Outside of Tracks

6.57 ft in

D

Length of Track on Ground

6.57 ft in

E

Ground Clearance

1.1 ft in

H

Tail Swing Radius

3.29 ft in

Undercarriage

N

Shoe Size

15.75 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2348

Engine Model

4TNV88

Gross Power

40 hp

Power Measured @

2500 rpm

Displacement

133.6 cu in

Operational

Operating Weight

10427.9 lb

Hydraulic System Relief Valve Pressure

3481 psi

Hydraulic Pump Flow Capacity

33.1 gal/min

Undercarriage

Shoe Size

15.8 in

Max Travel Speed

2.8 mph

Buckets

Reference Bucket Capacity

0.3 yd3

Boom/Stick Option (HEX) 1

Shipping Height of Unit

8.4 ft in

Shipping Length of Unit

18 ft in

Max Digging Depth

11.9 ft in

Max Reach Along Ground

19.7 ft in

Max Loading Height

13.5 ft in

Max Vertical Wall Digging Depth

9.4 ft in

Dimensions

Width to Outside of Tracks

6.6 ft in

Ground Clearance

1.1 ft in

Tail Swing Radius

3.3 ft in

Length of Track on Ground

6.6 ft in
