Zoomlion PY220 Motor Grader

Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Units

Dimensions

Dimensions

A

Overall Length

29.86ft in

B

Width Over Tires

8.52ft in


Specifications

Engine

Engine Make

2347

Engine Model

QSB6.7-C220

Power Measured @

2200rpm

Max Power

220hp

Operational

Std Operation Weight - Total

35935.4lb

Fuel Capacity

79.3gal

Hydraulic System Fluid Capacity

31.8gal

Circle Gearbox Fluid Capacity

7.4gal

Transmission

Max Speed - Forward

24.9mph

Max Speed - Reverse

15.6mph

Steering

Turning Radius

26ft in

Moldboard

Moldboard Width

14.1ft in

Moldboard Height

24.1in

Max Depth of Cut

19.7in

Circle

Max Lift Above Ground

18.2in

Dimensions

Height to Top of Isomount Cab

10.8ft in

Overall Length

29.9ft in

Width Over Tires

8.6ft in
