Yanmar T210-1 Multi Terrain Loader

Multi Terrain Loader
Multi Terrain Loader
Multi Terrain Loader
Multi Terrain Loader
Multi Terrain Loader
Multi Terrain Loader
Units

Dimensions

Dimensions

E

Ground Clearance

13in

I

Track Gauge

4.31ft in

H

Reach At Max Lift And Dump

1.12ft in

Front Departure Angle

29.2degrees

Grouser Height

0.09ft in

Hinge Pin Height - Fully Raised

128in

Length With Bucket

12.7ft in

Length With Out Bucket

9.55ft in

Max. Rollback Angle

102.5degrees

Operating Height - Fully Raised With Spillgaurd

172.01in

Overall Height, Rops Cab

83.12in

Overall Width Without Bucket

69.49in

Track Width

1.48ft in

Dump Angle

39degrees

Dump Height

7.98ft in

Crawler Length

4.87ft in

Track Shoe Width

1.48ft in

Undercarriage

Ground Pressure

4.7psi


Specifications

Engine

Fuel Tank

2.8gal

Number Of Cylinders

4

Engine Make

Yanmar

Engine Model

4TNV98CTNMSL

Engine Type

4-Stroke Turbo

Net Power

70.7hp

Peak Torque

206.1lb ft

Displacement

203cu in

Alternator

95amps

Capacities

Rated Operating Capacity

2101.1lb

Operational

Operating Weight

9890lb

Cooling System Fluid Capacity

3.9gal

Fuel Capacity

24.4gal

Hydraulic System Fluid Capacity

13.8gal

Drawbar Pull

12359lb

Max Speed - Low Range

5.5mph

Max Speed - High Range

7.9mph

Loader

Breakout Force

5491.8lb

Tipping Angle

6001degrees

Bucket Width

73.9in

Hydraulic

Auxiliary Hydraulic Flow

21.8gal/min
