XCMG QY50B Hydraulic Truck Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
36.98ft in
J
Max Height @ Max Raise Angle - No Jib
132.26ft in
K
Min Working Radius
9.85ft in
Swing Speed
2rpm
Max Lift Capacity
99999.92lb
Dimensions
A
Transport Length
43.54ft in
B
Transport Width
9.03ft in
C
Transport Height
10.83ft in
E
Ground Clearance
0.83ft in
F
Width W/ Outriggers Extended
21.66ft in
H
Upper Structure Tail Swing Radius
12.47ft in
Gradeability
46%
Approach Angle
16degrees
Angle Of Departure
10degrees
Specifications
Carrier Engine
Model
WD615.46
Gross Power
356.8hp
Power Measured @
2200rpm
Max Torque
1076.9lb ft
Torque Measured @
1400rpm
Operational
Operating Weight
87898.3lb
Transmission
Max Speed - Forward
48.5mph
