Volvo L220F Wheel Loader

Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

10.86 ft in

Dimensions

A

Length with Bucket on Ground

29.7 ft in

B

Width Over Tires

10.41 ft in

C

Height to Top of Cab

12.24 ft in

D

Wheelbase

12.14 ft in

E

Ground Clearance

1.78 ft in

F

Hinge Pin - Max Height

15.33 ft in

H

Reach at Max Lift and Dump

4.14 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2244

Engine Model

D12DLBE3

Net Power

347.4 hp

Gross Power

350.1 hp

Power Measured @

1600 rpm

Displacement

732.3 cu in

Torque Measured @

1400 rpm

Max Torque

1301.8

Aspiration

Turbocharged and Intercooled

Operational

Operating Weight

68762.2 lb

Fuel Capacity

88.5 gal

Hydraulic System Fluid Capacity

59.8 gal

Engine Oil Fluid Capacity

12.7 gal

Cooling System Fluid Capacity

11.1 gal

Transmission Fluid Capacity

11.9 gal

Front Axle/Diff Fluid Capacity

20.4 gal

Rear Axle/Diff Fluid Capacity

18.8 gal

Static Tipping Weight

52403.9 lb

Turning Radius

25.4 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

80 amps

Rear Axle Oscillation

15 degrees

Tire Size

29.5R25 L3

Transmission

Transmission Type

Automatic Powershift

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

22.4 mph

Max Speed - Reverse

22.4 mph

Hydraulic System

Relief Valve Setting

3771

Pump Flow Capacity

52.6 gal/min

Raise Time

5.8 sec

Dump Time

1.6 sec

Lower Time

3.2 sec

Bucket

Dump Clearance at Max Raise

10.9 ft in

Bucket Width

11.2 ft in

Bucket Capacity - heaped

6.5 yd3

Dimensions

Length with Bucket on Ground

29.7 ft in

Width Over Tires

10.5 ft in

Height to Top of Cab

12.3 ft in

Ground Clearance

1.8 ft in

Wheelbase

12.2 ft in

Hinge Pin - Max Height

15.4 ft in

Reach at Max Lift and Dump

4.2 ft in
