Volvo ECR235CL Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
29.79ft in
C
Shipping Height Of Unit
10.62ft in
I
Max Cutting Height
34.78ft in
J
Max Loading Height
24.84ft in
K
Max Reach Along Ground
30.65ft in
L
Max Vertical Wall Digging Depth
16.75ft in
M
Max Digging Depth
20.84ft in
Boom/Stick Option (Hex) 1
Boom 18'8" (5700mm)/Stick 8'2" (2500mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
29.48ft in
I
Max Cutting Height
35.82ft in
C
Shipping Height Of Unit
10.11ft in
J
Max Loading Height
25.86ft in
K
Max Reach Along Ground
31.91ft in
L
Max Vertical Wall Digging Depth
18.79ft in
M
Max Digging Depth
22.15ft in
Boom/Stick Option (Hex) 2
Boom 18'8" (5700mm)/Stick 9'6" (2900mm)
Dimensions
E
Ground Clearance
1.51ft in
G
Height To Top Of Cab
9.98ft in
B
Width To Outside Of Tracks
10.14ft in
D
Length Of Track On Ground
12.01ft in
H
Tail Swing Radius
5.52ft in
Removal Counterweight Clearance
3.37ft in
Undercarriage
F
Track Gauge
7.85ft in
N
Shoe Size
23.63in
Number Of Shoes Per Side
49
Drawbar Pull
44980lb
Number Of Track Rollers Per Side
9
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.3mph
Ground Pressure
7.7psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2244
Engine Model
D6E EAE3
Net Power
147hp
Gross Power
165hp
Power Measured @
1800rpm
Max Torque
546lb ft
Displacement
348cu in
Aspiration
Turbocharged with Intercooler
Torque Measured @
1350rpm
Operational
Operating Weight
56070lb
Fuel Capacity
85.9gal
Cooling System Fluid Capacity
7.1gal
Hydraulic System Fluid Capacity
58.2gal
Engine Oil Capacity
6.7gal
Operating Voltage
24V
Swing Drive Fluid Capacity
1.4gal
Alternator Supplied Amperage
80amps
Hydraulic System Relief Valve Pressure
4980psi
Hydraulic Pump Flow Capacity
106gal/min
Swing Mechanism
Swing Speed
10.8rpm
Swing Torque
lb ft
Buckets
Reference Bucket Capacity
1.6yd3
