Volvo EC15BXR Mini Excavator

Volvo EC15BXR Mini Excavator Specs front
Volvo EC15BXR Mini Excavator Specs front
Volvo EC15BXR Mini Excavator Specs side
Volvo EC15BXR Mini Excavator Specs side
Volvo EC15BXR Mini Excavator Specs extended
Volvo EC15BXR Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

11.98 ft in

C

Shipping Height of Unit

7.39 ft in

I

Max Cutting Height

11.19 ft in

J

Max Loading Height

8.14 ft in

K

Max Reach Along Ground

11.85 ft in

L

Max Vertical Wall Digging Depth

4.93 ft in

M

Max Digging Depth

6.73 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

11.98 ft in

C

Shipping Height of Unit

7.39 ft in

I

Max Cutting Height

11.65 ft in

J

Max Loading Height

8.6 ft in

K

Max Reach Along Ground

12.64 ft in

L

Max Vertical Wall Digging Depth

5.71 ft in

M

Max Digging Depth

7.55 ft in

Dimensions

B

Width to Outside of Tracks

4.73 ft in

D

Length of Track on Ground

3.43 ft in

E

Ground Clearance

0.69 ft in

G

Height to Top of Cab

7.39 ft in

H

Tail Swing Radius

3.68 ft in

Undercarriage

F

Track Gauge

3.22 ft in

N

Shoe Size

9 in


Specifications

Engine

Number of Cylinders

3

Engine Make

2251

Engine Model

L3E

Gross Power

19 hp

Net Power

15.5 hp

Power Measured @

2150 rpm

Displacement

58 cu in

Max Torque

39.9 lb ft

Torque Measured @

1850 rpm

Aspiration

Natural

Operational

Operating Weight

3261 lb

Fuel Capacity

5.6 gal

Cooling System Fluid Capacity

1.2 gal

Hydraulic System Fluid Capacity

1.7 gal

Engine Oil Capacity

0.3 gal

Operating Voltage

12 V

Alternator Supplied Amperage

40 amps

Hydraulic System Relief Valve Pressure

2465 psi

Hydraulic Pump Flow Capacity

8.5 gal/min

Swing Mechanism

Swing Speed

9 rpm

Undercarriage

Shoe Size

9 in

Ground Pressure

4 psi

Max Travel Speed

1.2 mph

Track Gauge

3.3 ft in

Buckets

Reference Bucket Capacity

0.1 yd3

Minimum Bucket Capacity

0.1 yd3

Maximum Bucket Capacity

0.1 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 5'9" (1750mm)/Stick 2'11" (900mm)

Shipping Height of Unit

7.4 ft in

Shipping Length of Unit

12 ft in

Max Digging Depth

6.8 ft in

Max Reach Along Ground

11.9 ft in

Max Cutting Height

11.2 ft in

Max Loading Height

8.2 ft in

Max Vertical Wall Digging Depth

5 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Boom 5'9" (1750mm)/Stick 3'9" (1150mm)

Shipping Height of Unit

7.4 ft in

Shipping Length of Unit

12 ft in

Max Digging Depth

7.6 ft in

Max Reach Along Ground

12.7 ft in

Max Cutting Height

11.7 ft in

Max Loading Height

8.6 ft in

Max Vertical Wall Digging Depth

5.8 ft in

Dimensions

Width to Outside of Tracks

4.8 ft in

Height to Top of Cab

7.4 ft in

Ground Clearance

0.7 ft in

Removal Counterweight Clearance

1.5 ft in

Tail Swing Radius

3.7 ft in

Length of Track on Ground

3.5 ft in
