Toyota 8FGCU32 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
8.22ft in
B
Overall Width
3.65ft in
C
Overall Height - Mast Lowered
6.73ft in
D
Wheelbase
4.88ft in
F
Height To Top Of Overhead Guard
6.73ft in
G
Max Fork Height
10.98ft in
Fork Spread Max
3.19ft in
Fork Spread Min-Outer Edge To Edge
9.85in
Free Lift
5.32in
Turning Radius
6.76ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
5degrees
Load Center
24.02in
Load Capacity
6613.87lb
Lift Speed
102ft/min
Specifications
Engine
Number Of Cylinders
4
Engine Make
TOYOTA
Engine Model
4Y - ECS
Power
51hp
Torque
87.1lb ft
Power Measured @
2570rpm
Displacement
136cu in
Torque Measured @
2100rpm
Operational
Operating Weight
9722.4lb
Tire Type
Cushion
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
10.6mph
Fuel Capacity
11.9gal
Hydraulic System Fluid Capacity
20gal
Hydraulic System Relief Valve Pressure
2275psi
Performance
Drawbar Pull Max -Full Load
40785.6lb
Drawbar Pull Max -No Load
16534.7lb
Transmission
Type -Tms870
Powershift
Number Of Forward / Reverse Speeds
1/1
Tires
Tires - Size_Front
21 x 8 x 15
Tires - Size_Rear
16 x 6 x 10-1/2
