Tigercat H09 Harvester

Units

Dimensions

Boom

H

Max Reach w/ Head

24.61 ft in

Dimensions

B

Overall Width

6.24 ft in

C

Height to Top of Cab

10.83 ft in

Undercarriage

E

Ground Clearance

1.84 ft in


Specifications

Engine

Engine Make

2358

Engine Model

NEF6

Gross Power

180 hp

Power Measured @

2100 rpm

Max Torque

516.3 lb ft

Torque Measured @

1300 rpm

Aspiration

Turbodiesel

Operational

Operating Weight

24200 lb

Fuel Capacity

52.9 gal

Hydraulic System Fluid Capacity

22.5 gal

Operating Voltage

24 V

Alternator Supplied Amperage

180 amps

Max Speed

8 mph

Transmission Type

2-speed hydrostatic

Undercarriage

Ground Clearance

1.9 ft in

DRIVE SYSTEM

Tire Size - front

400

Tire Size - rear

55 x 22.5

Boom

Max Reach w/ Head

24.7 ft in

Dimensions

Height to Top of Cab

10.9 ft in

Overall Width

6.3 ft in
