New Holland TC33D 4WD Tractor

4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
MODEL.UNITS

Dimensions

Dimensions

A

Overall Length

8.86in

B

Width Outside Frame

4.53ft in

C

Height To Top Of Cab

7.32ft in

D

Wheelbase

5.25in

E

Ground Clearance

14.02in

Tire Size

Front 7x14, Rear 11.2x24


Specifications

Engine

Number Of Cylinders

3

Engine Make

0

Gross Power

33hp

Pto Power

28.6hp

Power Measured @

2800rpm

Displacement

91.3cu in

Operational

Operating Weight

2474lb

Fuel Capacity

7.3gal

3 Point Hitch Lift Capacity @ 24 Inches

1635lb

Turning Radius

8.1ft in

Transmission

Transmission Type

Manual

Number Of Forward Gears

9

Number Of Reverse Gears

3

Max Speed

12.8mph

Hydraulic System

Pump Flow Capacity

12.7gal/min


MODEL.COMPARESIMILARM

MODEL.MANUFACTURERMOD

3 Point Hitch Lift Capacity @ 24 Inches

Gross Power

Operating Weight

3 Point Hitch Lift Capacity @ 24 Inches

1609.4 lb

Gross Power

33 hp

Operating Weight

2425.1 lb

3 Point Hitch Lift Capacity @ 24 Inches

1635 lb

Gross Power

29 hp

Operating Weight

2474 lb

3 Point Hitch Lift Capacity @ 24 Inches

1609.4 lb

Gross Power

28.4 hp

Operating Weight

2423 lb
