New Holland T4050 2WD Tractor

New Holland T4050 2WD Tractor Specs front
New Holland T4050 2WD Tractor Specs front
New Holland T4050 2WD Tractor Specs side
New Holland T4050 2WD Tractor Specs side
New Holland T4050 2WD Tractor Specs back
New Holland T4050 2WD Tractor Specs back
Units

Dimensions

Dimensions

A

Overall Length

11.55 in

D

Wheelbase

7.23 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2249

Engine Model

NEF

Gross Power

95 hp

PTO Power

80 hp

Power Measured @

2300 rpm

Displacement

274.7

Aspiration

turbocharged air to air intercooled

Operational

Fuel Capacity

21.7 gal

3 Point Hitch Lift Capacity @ 24 inches

3968.4 lb

Operating Voltage

12 V

Alternator Supplied Amperage

120 amps

Transmission

Transmission Type

16RX16R Synchro Command transmission with mechanical shuttle or clutchless power shuttle

Number of Forward Gears

16

Number of Reverse Gears

16

Max Speed

23.5 mph

Hydraulic System

Relief Valve Setting

2755

Pump Flow Capacity

25.5 gal/min

Number of Remote Control Valves

1

Dimensions

Wheelbase

7.3 ft in

Overall Length

11.6 in

Height with ROPS

7.7 ft in

Height with out ROPS

6.5 ft in


Compare similar models

Manufacturer / Model

Gross Power

3 Point Hitch Lift Capacity @ 24 inches

Gross Power

90 hp

3 Point Hitch Lift Capacity @ 24 inches

3968.4 lb

Gross Power

90 hp

3 Point Hitch Lift Capacity @ 24 inches

3968.4 lb

Gross Power

89 hp

3 Point Hitch Lift Capacity @ 24 inches

3947 lb
