New Holland EC350 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
37.08ft in
C
Shipping Height Of Unit
11.32ft in
I
Max Cutting Height
35.77ft in
J
Max Loading Height
26.25ft in
K
Max Reach Along Ground
36.42ft in
L
Max Vertical Wall Digging Depth
19.36ft in
M
Max Digging Depth
24.28ft in
Boom/Stick Option (Hex) 1
Boom - 21'4" (6.5 m) / Arm - 10'6" (3.2 m)
Dimensions
E
Ground Clearance
1.61ft in
G
Height To Top Of Cab
10.31ft in
B
Width To Outside Of Tracks
11.16ft in
D
Length Of Track On Ground
13.24ft in
H
Tail Swing Radius
10.83ft in
Removal Counterweight Clearance
3.84ft in
Undercarriage
F
Track Gauge
7.68ft in
N
Shoe Size
32in
Ground Pressure
7.1psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
6CTA 8.3
Net Power
249hp
Aspiration
Turbo Charged
Displacement
506.5cu in
Operational
Operating Weight
77382lb
Fuel Capacity
158.5gal
Cooling System Fluid Capacity
11.1gal
Hydraulic System Fluid Capacity
148gal
Engine Oil Capacity
6.1gal
Hydraulic System Relief Valve Pressure
4641psi
Hydraulic Pump Flow Capacity
150.6gal/min
Swing Mechanism
Swing Speed
9rpm
Swing Torque
83344lb ft
Buckets
Reference Bucket Capacity
1.8yd3
