New Holland 9682 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
265.75in
C
Height To Top Of Cab
11.39ft in
D
Wheelbase
132.68in
Overall Width
12.5ft in
Shipping Weight
19729.17lb
Specifications
Engine
Torque
1215lb ft
Number Of Cylinders
6
Engine Make
New Holland
Engine Model
Cummins N14
Gross Power
360hp
Pto Power
320hp
Power Measured @
2100rpm
Displacement
854.4cu in
Bore
5.6in
Stroke
6in
Aspiration
Turbocharged
Operational
Operating Weight
31865lb
Fuel Capacity
245gal
Hydraulic System Fluid Capacity
31gal
Front Diff Fluid Capacity
7.2gal
Rear Diff Fluid Capacity
2.1gal
Front Tire Size
20.8R42
3 Point Hitch Type
IVN/3
Rear Tire Size
20.8R42
3 Point Hitch Lift Capacity @ 24 Inches
12998.5lb
Alternator Supplied Amperage
130amps
Operating Voltage
12V
Transmission
Transmission Type
Partially synchronized
Number Of Forward Gears
12
Number Of Reverse Gears
4
Max Speed - Forward
17.1mph
Max Speed - Reverse
6.1mph
Hydraulic System
Hydraulic System Type
Closed center load sensing
Pump Flow Capacity
31gal/min
Relief Valve Pressure
2900psi
Number Of Remote Control Valves
1 to 4
