Mustang ME3703 Mini Excavator

Mustang ME3703 Mini Excavator Specs front
Mustang ME3703 Mini Excavator Specs front
Mustang ME3703 Mini Excavator Specs side
Mustang ME3703 Mini Excavator Specs side
Mustang ME3703 Mini Excavator Specs extended
Mustang ME3703 Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

13.17 ft in

C

Shipping Height of Unit

8.25 ft in

I

Max Cutting Height

17.25 ft in

J

Max Loading Height

12.58 ft in

K

Max Reach Along Ground

16.93 ft in

L

Max Vertical Wall Digging Depth

6.92 ft in

M

Max Digging Depth

1025 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

13.17 ft in

C

Shipping Height of Unit

8.25 ft in

I

Max Cutting Height

17.25 ft in

J

Max Loading Height

12.58 ft in

K

Max Reach Along Ground

16.93 ft in

L

Max Vertical Wall Digging Depth

6.92 ft in

M

Max Digging Depth

11.17 ft in

Dimensions

B

Width to Outside of Tracks

43.25 ft in

D

Length of Track on Ground

5.25 ft in

E

Ground Clearance

0.92 ft in

G

Height to Top of Cab

8.25 ft in

H

Tail Swing Radius

4.58 ft in

Undercarriage

F

Track Gauge

5.25 ft in

N

Shoe Size

12 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2348

Engine Model

4TNV88-WNS

Gross Power

48 hp

Net Power

32 hp

Displacement

133.6 cu in

Operational

Operating Weight

8215 lb

Hydraulic System Relief Valve Pressure

3481 psi

Hydraulic Pump Flow Capacity

28.2 gal/min

Swing Mechanism

Swing Speed

12 rpm

Swing Torque

6569 lb ft

Undercarriage

Shoe Size

12 in

Number of Carrier Rollers per Side

1

Number of Track Rollers per Side

4

Ground Pressure

5 psi

Max Travel Speed

3 mph

Drawbar Pull

10053 lb

Track Gauge

5.3 ft in

Buckets

Reference Bucket Capacity

0.2 yd3

Minimum Bucket Capacity

0.1 yd3

Maximum Bucket Capacity

0.3 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Standard Arm Length 4ft5.3in.(1354mm )

Shipping Height of Unit

8.3 ft in

Shipping Length of Unit

13.2 ft in

Max Digging Depth

1025 ft in

Max Reach Along Ground

17 ft in

Max Cutting Height

17.3 ft in

Max Loading Height

12.6 ft in

Max Vertical Wall Digging Depth

7 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Optional Arm Length 5.ft. 4.4in. (1636mm )

Shipping Height of Unit

8.3 ft in

Shipping Length of Unit

13.2 ft in

Max Digging Depth

11.2 ft in

Max Reach Along Ground

17 ft in

Max Cutting Height

17.3 ft in

Max Loading Height

12.6 ft in

Max Vertical Wall Digging Depth

7 ft in

Dimensions

Width to Outside of Tracks

43.3 ft in

Height to Top of Cab

8.3 ft in

Ground Clearance

1 ft in

Removal Counterweight Clearance

1.4 ft in

Tail Swing Radius

4.6 ft in

Length of Track on Ground

5.3 ft in
