Mustang 2066 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
10.76ft in
B
Width Over Tires
5.34ft in
E
Ground Clearance
7.9in
C
Height To Top Of Cab
6.76ft in
D
Wheelbase
3.59ft in
F
Length W/O Bucket
7.75ft in
G
Clearance At Max Lift And Dump
3.38ft in
H
Reach At Max Lift And Dump
95in
Turning Radius From Center - Machine Rear
62.6in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2348
Engine Model
4TNV98 / TIER III
Net Power
68hp
Power Measured @
2500rpm
Displacement
202cu in
Operational
Operational Weight
7460lb
Fuel Capacity
19gal
Hydraulic System Fluid Capacity
16gal
Max Speed
11.4mph
Operating Voltage
12V
Alternator Supplied Amperage
950amps
Loader
Breakout Force
6692lb
Operating Load Rating
2300lb
Tipping Angle
4000degrees
Bucket Capacity
0.7yd3
Hydraulic
Pump Flow Capacity
21.5gal/min
Relief Valve Pressure
3000psi
