Manitou ME 320 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
6.7ft in
B
Overall Width
3.1ft in
C
Overall Height - Mast Lowered
6.6ft in
D
Wheelbase
4.1ft in
E
Ground Clearance
3.55in
F
Height To Top Of Overhead Guard
6.56ft in
G
Max Fork Height
10.83ft in
Right Angle Stack
0.4ft in
Turning Radius
5.5ft in
Mast
H
Mast Tip Forward
6.5degrees
I
Mast Tip Rear
6.5degrees
Max Fork Spread
41.54in
Lower Speed
_-
Load Center
19.69in
Load Capacity
4409.25lb
Lift Speed
_-
Specifications
Engine
Power
11.6hp
Fuel Type
battery
Operational
Operating Weight
7650.1lb
Tire Type
front 200/50-10 rear 15x4.5-8
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
8.1mph
Performance
Lift Capacity At Max - Height
4409.3lb
Travel Speed
9.4mph
Drawbar Pull Force
2023.3lb
Hydraulic
Pressure
2610.7psi
