Link-Belt RTC8050 Series II Rough Terrain Crane

Link-Belt RTC8050 Series II Rough Terrain Crane Specs front
Link-Belt RTC8050 Series II Rough Terrain Crane Specs front
Link-Belt RTC8050 Series II Rough Terrain Crane Specs side
Link-Belt RTC8050 Series II Rough Terrain Crane Specs side
Link-Belt RTC8050 Series II Rough Terrain Crane Specs extended
Link-Belt RTC8050 Series II Rough Terrain Crane Specs extended
Units

Dimensions

Boom

I

Min Height @ Max Raise Angle

43 ft in

J

Max Height @ Max Raise Angle - no jib

118.44 ft in

K

Min Operating Radius

10 ft in

L

Max Operating Radius

100 ft in

M

Max Elevating Angle

78 degrees

Dimensions

A

Transport Length

43.74 ft in

B

Transport Width

9.59 ft in

C

Transport Height

11.98 ft in

D

Wheelbase

150.79 in

E

Ground Clearance

0.83 ft in

F

Width w/ Outriggers Extended

22.51 ft in

G

Carrier/Base Length

25623.36 ft in

H

Upper Structure Tail Swing Radius

12.83 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

Cummins QSB

Engine Model

C6.6

Emissions compliance

Tier 4F / Stage IV

Gross Power

195 hp

Power Measured @

2300 rpm

Max Torque

590.1 lb ft

Torque Measured @

1500 rpm

Displacement

408.9 cu in

Bore

4.3 in

Stroke

4.9 in

Crankcase capacity

14.2 L

Operational

DEF tank capacity

5 gal

Operating Weight

74659.6 lb

Fuel Capacity

75 gal

Hydraulic System Fluid Capacity

131.1 gal

Engine Oil Capacity

4.6 gal

Operating Voltage

12 V

Alternator Supplied Amperage

160 amps

Tire Size

23.5x25

Transmission

Transmission Type

Full automatic

Number of Forward Gears

6

Number of Reverse Gears

6

Max Speed - Forward

19.6 mph

Max Speed - Reverse

4 mph

Boom

Number of Sections

4

Min Height @ Max Raise Angle

43 ft in

Max Height @ Max Raise Angle - no jib

118.5 ft in

Max Elevating Angle

78 degrees

Max Lift Capacity

100000 lb

Swing Speed

2.5 rpm

Min Operating Radius

10 ft in

Max Operating Radius

100 ft in

Dimensions

Transport Length

43.8 ft in

Transport Width

9.6 ft in

Transport Height

12 ft in

Ground Clearance

0.9 ft in

Wheelbase

150.8 in

Width w/ Outriggers Extended

22.6 ft in

Carrier/Base Length

25623.4 ft in

Upper Structure Tail Swing Radius

12.9 ft in
