Link-Belt 160LX Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
27.56ft in
C
Shipping Height Of Unit
9.68ft in
I
Max Cutting Height
30.52ft in
J
Max Loading Height
21.89ft in
K
Max Reach Along Ground
29.43ft in
L
Max Vertical Wall Digging Depth
17.07ft in
M
Max Digging Depth
20.08ft in
Boom/Stick Option (Hex) 1
Boom 16\'11\" (5150mm) / Stick 8\'10\" (2700mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
27.7ft in
I
Max Cutting Height
31.47ft in
C
Shipping Height Of Unit
10.18ft in
J
Max Loading Height
22.81ft in
K
Max Reach Along Ground
30.58ft in
L
Max Vertical Wall Digging Depth
18.64ft in
M
Max Digging Depth
21.17ft in
Boom/Stick Option (Hex) 2
Boom 16\'11\" (5150mm) / Stick 10\'0\" (3050mm)
Dimensions
E
Ground Clearance
1.45ft in
G
Height To Top Of Cab
9.68ft in
B
Width To Outside Of Tracks
8.5ft in
D
Length Of Track On Ground
10.14ft in
H
Tail Swing Radius
7.78ft in
Removal Counterweight Clearance
3.35ft in
Undercarriage
F
Track Gauge
6.53ft in
N
Shoe Size
23.63in
Ground Pressure
5.77psi
Number Of Shoes Per Side
43
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.6mph
Number Of Track Rollers Per Side
7
Specifications
Engine
Number Of Cylinders
4
Engine Make
2353
Engine Model
DD-4BG1T
Net Power
101hp
Power Measured @
2200rpm
Max Torque
311lb ft
Aspiration
Turbocharged
Displacement
264cu in
Torque Measured @
1600rpm
Operational
Operating Weight
36200lb
Fuel Capacity
66.1gal
Cooling System Fluid Capacity
4.7gal
Hydraulic System Fluid Capacity
39.1gal
Engine Oil Capacity
4gal
Operating Voltage
24V
Alternator Supplied Amperage
40amps
Hydraulic System Relief Valve Pressure
4970psi
Hydraulic Pump Flow Capacity
72.4gal/min
Swing Mechanism
Swing Speed
11.4rpm
Swing Torque
33260lb ft
Buckets
Reference Bucket Capacity
0.8yd3
Minimum Bucket Capacity
0.6yd3
Maximum Bucket Capacity
1.2yd3
