Link-Belt 110 RT Rough Terrain Crane
Units
Dimensions
Boom
K
Min Operating Radius
7.16ft in
M
Max Elevating Angle
80degrees
Dimensions
A
Transport Length
47.64ft in
B
Transport Width
11.52ft in
C
Transport Height
13.33ft in
D
Wheelbase
172.05in
E
Ground Clearance
1.81ft in
F
Width W/ Outriggers Extended
25.96ft in
G
Carrier/Base Length
27132.55ft in
H
Upper Structure Tail Swing Radius
13.82ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
Cummins QSB
Engine Model
C6.6
Emissions Compliance
Tier 4F / Stage IV
Gross Power
270hp
Power Measured @
2000rpm
Max Torque
730.2lb ft
Torque Measured @
1500rpm
Displacement
408.9cu in
Bore
4.3in
Stroke
4.9in
Crankcase Capacity
14.2 L
Operational
Def Tank Capacity
5gal
Operating Weight
87534.6lb
Fuel Capacity
75gal
Hydraulic System Fluid Capacity
153gal
Operating Voltage
12V
Alternator Supplied Amperage
190amps
Tire Size
29.5 x 25
Transmission
Transmission Type
Powershift
Number Of Forward Gears
6
Number Of Reverse Gears
6
Max Speed - Forward
18.6mph
Max Speed - Reverse
18.6mph
