LeTourneau L1350 High Lift Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
23.56ft in
Bucket Capacity - Heaped
26.01yd3
Bucket Width
20.58ft in
Breakout Force
217930lb
Dimensions
E
Ground Clearance
2.43ft in
A
Length With Bucket On Ground
57.19ft in
B
Width Over Tires
18.94ft in
C
Height To Top Of Cab
19.79ft in
D
Wheelbase
21.26ft in
F
Hinge Pin - Max Height
29.86ft in
H
Reach At Max Lift And Dump
9.45ft in
Specifications
Engine
Number Of Cylinders
12
Engine Make
2347
Engine Model
QSK 45
Gross Power
1600hp
Power Measured @
1900rpm
Displacement
2746cu in
Aspiration
turbocharged
Operational
Operating Weight
405000.3lb
Fuel Capacity
924.9gal
Hydraulic System Fluid Capacity
374.9gal
Cooling System Fluid Capacity
101gal
Transmission Fluid Capacity
7.2gal
Front Axle/Diff Fluid Capacity
36gal
Rear Axle/Diff Fluid Capacity
36gal
Static Tipping Weight
210508.5lb
Turning Radius
42.1ft in
Rear Axle Oscillation
22degrees
Tire Size
50/80-57 68PR (L-4)
Transmission
Transmission Type
infinitely variable
Max Speed - Forward
10.1mph
Max Speed - Reverse
10.1mph
Hydraulic System
Relief Valve Setting
3300psi
Pump Flow Capacity
374.9gal/min
Raise Time
13sec
Dump Time
3sec
Lower Time
5sec
Pump Type
piston
