Kubota M6-111DTCC-F MFWD Tractor
Units
Dimensions
Dimensions
A
Overall Length
165.36in
D
Wheelbase
7.99ft in
B
Overall Width
6.89ft in
E
Ground Clearance
19.49in
Overall Height
9.32ft in
Front Tread Range
66.15in
Rear Tread Range
80.32in
Turning Radius Without Brakes 1
13.13ft in
Specifications
Engine
Battery
12V, 100Ah at 20hours, 900CCA
Number Of Cylinders
4
Engine Make
KUBOTA
Engine Model
V3800-TIEF4
Engine Type
Direct Injection
Gross Power
114.1hp
Net Power
106.8hp
Air Cleaner
8 Dry, dual-element
Pto Power
92hp
Power Measured @
2600rpm
Displacement
230cu in
Aspiration
Turbocharger with intercooler
Bore
4in
Stroke
4.8in
Alternator
130amps
Model Name
M6-111DTCC-F
Capacities
Diesel Exhaust Fluid (Def) Tank
4.3gal
Fuel Tank
50.2gal
Transmission
4gal
Engine Oil
2.8gal
Engine Coolant
2.7gal
Operational
Operating Weight
9788.6lb
Tires
Front - 13.6R24 , Rear - 18.4R34
3 Point Hitch Type
Telescopic lower link ends, telescopic stabilizers
3 Point Hitch Lift Capacity @ 24 Inches
6834.4lb
Power Take-Off(Pto)
Pto Speed Rear
540rpm
Pto Speed Mid
1000rpm
Mid- Pto
21 splines
Pto
Live-independent PTO
Rear Pto
6 splines
Transmission
Brake Type
Hydraulically operated wet disc brakes
Max Speed
21.9mph
Hydraulic System
System Pressure
2842.8psi
Hydraulic System
Electronic draft control
Pump Flow Capacity
18.7gal/min
