Kubota M5660SUH 2WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
138.78in
D
Wheelbase
6.85ft in
B
Overall Width
6.11ft in
E
Ground Clearance
16.34in
Height With Rops
7.94ft in
Front Tread Range
71.66in
Rear Tread Range
67.72in
Specifications
Engine
Number Of Cylinders
4
Engine Make
KUBOTA
Engine Type
4 cylinder in-line, Common Rail Sytem, direct injection
Net Power
56hp
Gross Power
57.9hp
Air Cleaner
Dry, dual element
Pto Power
50hp
Power Measured @
2600rpm
Displacement
148.5 cu. in.
Aspiration
Turbocharged
Alternator
45amps
Operational
Operating Weight
4188.8lb
Fuel Capacity
17.7gal
Hydraulic System Fluid Capacity
10.6gal
3 Point Hitch Type
Category I & II
3 Point Hitch Lift Capacity @ 24 Inches
3307lb
Turning Radius
11.9ft in
Power Take-Off(Pto)
Pto Speed
540rpm
Power Take-Off(Pto) Type
Live-independent, hydraulic PTO
Transmission
Shuttle (Forward-Reverse)
Hydraulic shuttle
Brake Type
Mechanical wet disc
Clutch Disk Diameter Wet Clutch
Multiple wet disk
Differential Lock
Rear standard (mechanical)
Number Of Forward Gears
8
Number Of Reverse Gears
8
Max Speed
18.3mph
Tires
Standard_Option_Front
6.5–16
Standard_Option_Rear
14.9–28
Hydraulic System
Controls
Position
Number Of Remote Control Valves
1 (2nd, 3rd & flow control valve optional)
