Krupp KMK4085 All Terrain Crane

Krupp KMK4085 All Terrain Crane Specs front
Krupp KMK4085 All Terrain Crane Specs front
Krupp KMK4085 All Terrain Crane Specs side
Krupp KMK4085 All Terrain Crane Specs side
Krupp KMK4085 All Terrain Crane Specs extend
Krupp KMK4085 All Terrain Crane Specs extend
Units

Dimensions

Boom

I

Min Height @ Max Raise Angle

47 ft in

J

Max Height @ Max Raise Angle - no jib

137 ft in

K

Min Working Radius

10 ft in

L

Max Working Radius

110 ft in

M

Max Elevating Angle

84 degrees

Dimensions

A

Transport Length

44.33 ft in

B

Transport Width

8.25 ft in

C

Transport Height

11.83 ft in

F

Width w/ Outriggers Extended

23.58 ft in

G

Carrier Length

34.67 ft in

H

Upper Structure Tail Swing Radius

13.33 ft in


Specifications

UPPER STRUCTURE ENGINE

Make

Krupp

CARRIER ENGINE

Make

Krupp

Model

OM 442 A diesel

Gross Power

362.1 hp

Power Measured @

2100 rpm

Max Torque

1180.1 lb ft

Torque Measured @

1500 rpm

Operational

Operating Weight

160000 lb

Number of Axels

4

Upper Structure Fuel Capacity

100 gal

Carrier Fuel Capacity

100 gal

Upper Structure Hydraulic System Fluid Capacity

225 gal

Operating Voltage

24 V

Alternator Supplied Amperage

55 amps

Tire Size

14.00R25

Transmission

Transmission Type

ZF 5-special-automatic 5 HP 600

Number of Forward Gears

5

Number of Reverse Gears

1

Max Speed - Forward

43.1 mph

Max Speed - Reverse

8.9 mph

Boom

Number of Sections

3

Min Height @ Max Raise Angle

47 ft in

Max Height @ Max Raise Angle - no jib

137 ft in

Max Elevating Angle

84 degrees

Max Lift Capacity

170000 lb

Min Working Radius

10 ft in

Max Working Radius

110 ft in

Swing Speed

2.4 rpm

Dimensions

Transport Length

44.4 ft in

Transport Width

8.3 ft in

Transport Height

11.9 ft in

Width w/ Outriggers Extended

23.6 ft in

Carrier Length

34.7 ft in

Upper Structure Tail Swing Radius

13.4 ft in
