Komatsu PC800LC-8 Material Handler
Units
Dimensions
Boom/Stick Option (Mat) 1
I
Max Height
60.37ft in
J
Max Reach Along Ground
55.12ft in
K
Max Depth
18.5ft in
Boom/Stick Option (Mat) 1
2-piece front 16.8m 55\'
Boom/Stick Option (Mat) 2
I
Max Height
72.84ft in
J
Max Reach Along Ground
67.92ft in
K
Max Depth
25ft in
Boom/Stick Option (Mat) 2
2-piece front 20.7m 68\'
Specifications
Engine
Number Of Cylinders
6
Engine Make
2238
Engine Model
SAA6D140E-5
Gross Power
496.2hp
Net Power
486.8hp
Power Measured @
1800rpm
Displacement
930.1cu in
Aspiration
turbocharged, aftercooled
Operational
Operating Weight W/O Attachment
196958.8lb
Fuel Capacity
258.9gal
Cooling System Fluid Capacity
26.5gal
Engine Oil Capacity
15.4gal
Hydraulic System Fluid Capacity
116.3gal
Operating Voltage
24V
Alternator Supplied Amperage
75amps
Max Drawbar Pull
125660lb
Swing Mechanism
Swing Torque
209461lb ft
Swing Speed
6.8rpm
Transmission
Transmission Type
Hydrostatic
Number Of Forward Gears
2
Max Speed
2.7mph
Track Undercarriage
Shoe Size
31.9in
Track Gauge
11.5ft in
Number Of Shoes Per Side
51
Number Of Track Rollers Per Side
9
Length Of Track On Ground
16.5ft in
Hydraulic
Pump Type
Variable-capacity piston pumps
Pump Capacity
261.1gal/min
Relief Pressure
4980psi
