Komatsu PC380LC-6 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
36.95ft in
C
Shipping Height Of Unit
11.56ft in
I
Max Cutting Height
31.91ft in
J
Max Loading Height
22.15ft in
K
Max Reach Along Ground
32.62ft in
L
Max Vertical Wall Digging Depth
16.31ft in
M
Max Digging Depth
20.43ft in
Boom/Stick Option (Hex) 1
boom w/ stick 2200mm
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
36.59ft in
I
Max Cutting Height
33.17ft in
C
Shipping Height Of Unit
11.19ft in
J
Max Loading Height
23.13ft in
K
Max Reach Along Ground
33.95ft in
L
Max Vertical Wall Digging Depth
18.72ft in
M
Max Digging Depth
21.58ft in
Boom/Stick Option (Hex) 2
boom w/ stick 2550mm
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
36.42ft in
I
Max Cutting Height
33.95ft in
J
Max Loading Height
23.77ft in
C
Shipping Height Of Unit
10.68ft in
K
Max Reach Along Ground
35.83ft in
L
Max Vertical Wall Digging Depth
20.82ft in
M
Max Digging Depth
23.77ft in
Boom/Stick Option (Hex) 3
boom w/ stick 3185mm
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
36.54ft in
C
Shipping Height Of Unit
11.91ft in
I
Max Cutting Height
35.06ft in
J
Max Loading Height
25.05ft in
K
Max Reach Along Ground
38.46ft in
M
Max Digging Depth
26.4ft in
Boom/Stick Option (Hex) 4
boom w/ stick 4020mm
Max Vertical Wall Dig Depth
23.43ft in
Dimensions
E
Ground Clearance
1.82ft in
G
Height To Top Of Cab
10.71ft in
B
Width To Outside Of Tracks
11.39ft in
D
Length Of Track On Ground
14.27ft in
H
Tail Swing Radius
11.1ft in
Removal Counterweight Clearance
4.33ft in
Undercarriage
F
Track Gauge
9.42ft in
N
Shoe Size
23.63in
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.36mph
Ground Pressure
10psi
Number Of Track Rollers Per Side
8
Number Of Shoes Per Side
49
Drawbar Pull
76055lb
Specifications
Engine
Number Of Cylinders
6
Engine Make
2238
Engine Model
SAA6D108-2
Net Power
232hp
Power Measured @
1750rpm
Displacement
504.7cu in
Operational
Operating Weight
87744lb
Fuel Capacity
142.7gal
Cooling System Fluid Capacity
8gal
Hydraulic System Fluid Capacity
54.2gal
Engine Oil Capacity
7.4gal
Swing Drive Fluid Capacity
3.4gal
Hydraulic System Relief Valve Pressure
5049.3psi
Hydraulic Pump Flow Capacity
141.6gal/min
Swing Mechanism
Swing Speed
10rpm
Buckets
Reference Bucket Capacity
1.8yd3
