Komatsu PC180LC-6 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
27.96ft in
C
Shipping Height Of Unit
10.26ft in
I
Max Cutting Height
28.79ft in
J
Max Loading Height
20.12ft in
K
Max Reach Along Ground
26.84ft in
L
Max Vertical Wall Digging Depth
14.79ft in
M
Max Digging Depth
17.07ft in
Boom/Stick Option (Hex) 1
Monoboom w/ stick 1850mm
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
28.09ft in
I
Max Cutting Height
29.01ft in
C
Shipping Height Of Unit
9.72ft in
J
Max Loading Height
20.44ft in
K
Max Reach Along Ground
27.92ft in
L
Max Vertical Wall Digging Depth
16.53ft in
M
Max Digging Depth
18.41ft in
Boom/Stick Option (Hex) 2
Monoboom w/ stick 2250mm
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
28.09ft in
I
Max Cutting Height
29.2ft in
J
Max Loading Height
20.74ft in
C
Shipping Height Of Unit
9.73ft in
K
Max Reach Along Ground
28.88ft in
L
Max Vertical Wall Digging Depth
16.53ft in
M
Max Digging Depth
19.56ft in
Boom/Stick Option (Hex) 3
Monoboom w/ stick 2620mm
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
28.12ft in
C
Shipping Height Of Unit
10.03ft in
I
Max Cutting Height
29.71ft in
J
Max Loading Height
21.23ft in
K
Max Reach Along Ground
29.78ft in
M
Max Digging Depth
20.51ft in
Max Vertical Wall Dig Depth
18.85ft in
Boom/Stick Option (Hex) 4
Monoboom w/ stick 2900mm
Boom/Stick Option (Hex) 5
I
Max Cutting Height
28.66ft in
J
Max Loading Height
19.99ft in
K
Max Reach Along Ground
26.88ft in
M
Max Digging Depth
17.2ft in
Boom/Stick Option (Hex) 5
two piece boom w/ stick 1850mm
Max Vertical Wall Dig Depth
14.92ft in
Boom/Stick Option (Hex) 6
I
Max Cutting Height
28.88ft in
J
Max Loading Height
20.31ft in
K
Max Reach Along Ground
27.94ft in
M
Max Digging Depth
18.53ft in
Boom/Stick Option (Hex) 6
two piece bomo w/ stick 2250mm
Max Vertical Wall Dig Depth
16.66ft in
Dimensions
E
Ground Clearance
1.46ft in
G
Height To Top Of Cab
9.42ft in
B
Width To Outside Of Tracks
9.13ft in
D
Length Of Track On Ground
10.7ft in
H
Tail Swing Radius
7.93ft in
Removal Counterweight Clearance
3.38ft in
Undercarriage
F
Track Gauge
7.16ft in
N
Shoe Size
23.63in
Drawbar Pull
30424lb
Number Of Track Rollers Per Side
7
Ground Pressure
6psi
Number Of Shoes Per Side
45
Max Travel Speed
3.42mph
Number Of Carrier Rollers Per Side
2
Specifications
Engine
Number Of Cylinders
4
Engine Make
2238
Engine Model
SA4D102E
Net Power
107hp
Gross Power
113hp
Power Measured @
2100rpm
Displacement
239.3cu in
Aspiration
Turbocharged
Operational
Operating Weight
39462.8lb
Fuel Capacity
66gal
Cooling System Fluid Capacity
5.3gal
Hydraulic System Fluid Capacity
31.7gal
Engine Oil Capacity
4.3gal
Operating Voltage
24V
Swing Drive Fluid Capacity
1.1gal
Alternator Supplied Amperage
55amps
Hydraulic Pump Flow Capacity
73gal/min
Swing Mechanism
Swing Speed
12rpm
