Komatsu D41S-3 Crawler Loader
Units
Dimensions
Dimensions
A
Length With Bucket On Ground
16.05ft in
E
Ground Clearance
1.19ft in
B
Width To Outside Of Tracks
6.37ft in
C
Height To Top Of Cab
9.83ft in
G
Clearance At Full Height And Dump
8.54ft in
H
Reach At Dump Height
3.38ft in
Undercarriage
I
Track Gauge
60.63in
D
Length Of Track On Ground
6.76ft in
Ground Pressure
9.53psi
Number Of Track Rollers Per Side
5
Track Shoe Width
15.75in
Specifications
Engine
Engine Make
2238
Engine Model
6D105
Net Power
90hp
Displacement
396cu in
Operational
Operating Weight
24339.1lb
Fuel Capacity
64.8gal
Cooling System Fluid Capacity
8.8gal
Static Tipping Load
15500lb
Breakout Force - Std Bucket
18700lb
Bucket Capacity - Heaped
1.6yd3
Max Speed
4.8mph
