Komatsu D355A-5 Crawler Tractor

Komatsu D355A-5 Crawler Tractor Specs front
Komatsu D355A-5 Crawler Tractor Specs front
Komatsu D355A-5 Crawler Tractor Specs side
Komatsu D355A-5 Crawler Tractor Specs side
Komatsu D355A-5 Crawler Tractor Specs back
Komatsu D355A-5 Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

30.19 ft in

B

Width Over Tracks

9.95 ft in

C

Height to Top of Cab

13.54 ft in

D

Length of Track on Ground

11.03 ft in

E

Ground Clearance

1.89 ft in

F

Length w/o Blade

18.57 ft in

Undercarriage

G

Track Gauge

7.42 ft in

H

Standard Shoe Size

24.02 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2238

Engine Model

SA6D155-4

Gross Power

410 hp

Power Measured @

2000 rpm

Displacement

1175.4 cu in

Operational

Operating Weight

9806.2 lb

Transmission

Transmission Type

TF

Number of Forward Gears

4

Number of Reverse Gears

4

Undercarriage

Standard Shoe Size

24.1 in

Number of Shoes per Side

39

Number of Track Rollers per Side

7

Number of Carrier Rollers per Side

2

Track Pitch

10.3 in

Track Gauge

7.5 ft in

Standard Blade

Width

14.2 ft in

Height

73.9 in

Dimensions

Length w/o Blade

18.6 ft in

Length w/ Blade

30.2 ft in

Width Over Tracks

10 ft in

Height to Top of Cab

13.6 ft in

Length of Track on Ground

11.1 ft in

Ground Clearance

1.9 ft in
