Komatsu CK35-1 Multi Terrain Loader

Komatsu CK35-1 Multi Terrain Loader Specs front
Komatsu CK35-1 Multi Terrain Loader Specs front
Komatsu CK35-1 Multi Terrain Loader Specs back
Komatsu CK35-1 Multi Terrain Loader Specs back
Komatsu CK35-1 Multi Terrain Loader Specs extended
Komatsu CK35-1 Multi Terrain Loader Specs extended
Units

Dimensions

Dimensions

B

Width Over Tracks

6.67 ft in

C

Height to Top of Cab

6.99 ft in

G

Clearance at Max Lift and Dump

11.73 ft in

H

Reach at Max Lift and Dump

2.86 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2238

Engine Model

S4D98E-2NFE

Net Power

84 hp

Power Measured @

2500 rpm

Peak Torque

211 lb ft

Torque Measured @

1600 rpm

Displacement

207.5 cu in

Aspiration

turbocharged

Operational

Operating Weight

9546.1 lb

Fuel Capacity

17 gal

Cooling System Fluid Capacity

2.2 gal

Engine Oil Capacity

3.4 gal

Hydraulic System Fluid Capacity

10.1 gal

Operating Voltage

12 V

Alternator Supplied Amperage

40 amps

Max Speed - low range

4.6 mph

Max Speed - high range

7.5 mph

Loader

Operating Load

2755.8 lb

Tipping Angle

7870.6 degrees

Bucket Capacity

0.7 yd3

Hydraulic

Pump Type

komatsu closed load sensing system

Pump Flow

21.2 gal/min

Relief Valve Pressure

3045 psi

Dimensions

Width Over Tracks

6.7 ft in

Length with Bucket

11.7 ft in

Height to Top of Cab

7 ft in

Clearance at Max Lift and Dump

11.8 ft in

Reach at Max Lift and Dump

2.9 ft in

Turning Radius from Center - machine rear

62.6 in

Turning Radius from Center - inc bucket

88.8 in
