Kobelco SK295LC-8 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
33.47ft in
C
Shipping Height Of Unit
10.5ft in
I
Max Cutting Height
33.27ft in
J
Max Loading Height
23.73ft in
K
Max Reach Along Ground
34.62ft in
M
Max Digging Depth
23.69ft in
Boom/Stick Option (Hex) 1
Boom 20\'4\" (6200mm) / Stick 10\'2\" (3100mm)
Dimensions
E
Ground Clearance
1.65ft in
G
Height To Top Of Cab
10.41ft in
B
Width To Outside Of Tracks
11.13ft in
D
Length Of Track On Ground
13.13ft in
H
Tail Swing Radius
9.75ft in
Removal Counterweight Clearance
3.94ft in
Undercarriage
F
Track Gauge
8.5ft in
N
Shoe Size
31.5in
Max Travel Speed
3.6mph
Drawbar Pull
57100lb
Ground Pressure
6.5psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2562
Engine Model
F4HE9684B*J1
Net Power
197hp
Gross Power
204hp
Power Measured @
2100rpm
Max Torque
673lb ft
Aspiration
Turbocharged
Displacement
410cu in
Torque Measured @
1400rpm
Operational
Operating Weight
66800lb
Fuel Capacity
122gal
Cooling System Fluid Capacity
6.6gal
Hydraulic System Fluid Capacity
74gal
Operating Voltage
24V
Engine Oil Capacity
4.8gal
Alternator Supplied Amperage
70amps
Hydraulic System Relief Valve Pressure
4970psi
Hydraulic Pump Flow Capacity
130gal/min
Swing Mechanism
Swing Speed
11rpm
Swing Torque
70732lb ft
Buckets
Reference Bucket Capacity
1.2yd3
Minimum Bucket Capacity
0.9yd3
Maximum Bucket Capacity
1.9yd3
