Jonyang JY210E Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
32.03ft in
C
Shipping Height Of Unit
10.77ft in
I
Max Cutting Height
30.28ft in
J
Max Loading Height
21.04ft in
K
Max Reach Along Ground
32.81ft in
M
Max Digging Depth
21.46ft in
Boom/Stick Option (Hex) 1
Boom 5710mm/Stick 2920mm
Dimensions
E
Ground Clearance
1.53ft in
G
Height To Top Of Cab
9.04ft in
B
Width To Outside Of Tracks
9.85ft in
D
Length Of Track On Ground
12.21ft in
H
Tail Swing Radius
9.65ft in
Removal Counterweight Clearance
3.48ft in
Undercarriage
F
Track Gauge
7.88ft in
N
Shoe Size
23.63in
Max Travel Speed
3.11mph
Ground Pressure
6.53psi
Specifications
Engine
Engine Make
2301
Engine Model
Cummins 6A5, 9-C
Net Power
169hp
Operational
Operating Weight
42000lb
Hydraulic System Relief Valve Pressure
4351.2psi
Hydraulic Pump Flow Capacity
124.2gal/min
Swing Mechanism
Swing Speed
13rpm
