John Deere TC44H Integrated Tool Carrier

John Deere TC44H Integrated Tool Carrier Specs front
John Deere TC44H Integrated Tool Carrier Specs front
John Deere TC44H Integrated Tool Carrier Specs extended_1
John Deere TC44H Integrated Tool Carrier Specs extended_1
John Deere TC44H Integrated Tool Carrier Specs extended_2
John Deere TC44H Integrated Tool Carrier Specs extended_2
John Deere TC44H Integrated Tool Carrier Specs extended_3
John Deere TC44H Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

22.87 ft in

B

Width Over Tires

7.65 ft in

C

Height to Top of Cab

10.26 ft in

D

Wheelbase

9.03 ft in

E

Ground Clearance

1.17 ft in

F

Hinge Pin Max Height

12.09 ft in

G

Dump Clearance at Max Lift

8.78 ft in

I

Fork Tine Length

4.01 ft in

K

Max Lift Height

11.46 ft in

L

Hook Height at Max Lift - standard

18.07 ft in

M

Hook Height at Max Lift - extended

22.6 ft in

N

Hook Reach at Max Lift - standard

7.2 ft in

O

Hook Reach at Max Lift - extended

11.51 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2240

Engine Model

4045T

Gross Power

116 hp

Net Power

110 hp

Power Measured @

2200 rpm

Max Torque

325 lb ft

Torque Measured @

1400 rpm

Displacement

276

Aspiration

Turbocharger

Operational

Operating Weight

228513 lb

Fuel Capacity

48 gal

Cooling System Fluid Capacity

5.1 gal

Engine Oil Capacity

3.4 gal

Transmission Fluid Capacity

3.4 gal

Front Diff Fluid Capacity

4 gal

Rear Diff Fluid Capacity

4 gal

Hydraulic System Fluid Capacity

28 gal

Turning Radius

15.5 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

55 amps

Rear Axle Oscillation

24 degrees

Static Tipping Load - Bucket

13190 lb

Static Tipping Load - Forks

10333 lb

Static Tipping Load - Material Handler

6860 lb

Tire Size

17.5-25

Transmission

Transmission Type

Power Shift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed Forward

24.8 mph

Max Speed Reverse

16.3 mph

Hydraulic System

Pump Type

Piston Pump

Relief Valve Setting

3600

Pump Flow Capacity

36 gal/min

Raise Time

5 sec

Dump Time

1.5 sec

Lower Time

2.3 sec

Bucket

Breakout Force

1795773.7 lb

Bucket Capacity - heaped

2.5 yd3

Bucket Capacity - struck

2.1 yd3

Dimensions

Width Over Tires

7.7 ft in

Height to Top of Cab

10.3 ft in

Wheelbase

9.1 ft in

Ground Clearance

1.2 ft in

Hinge Pin Max Height

12.1 ft in

Length w/ Bucket on Ground

22.9 ft in

Dump Clearance at Max Lift

8.8 ft in

Reach at Max Height and Dump

4.2 ft in

Fork Tine Length

4.1 ft in

Length with out Forks on Ground

24.2 ft in

Max Lift Height

11.5 ft in

Hook Height at Max Lift - Standard

18.1 ft in

Hook Height at Max Lift - Extended

22.6 ft in

Hook Reach at Max Lift - Standard

7.2 ft in

Hook Reach at Max Lift - Extended

11.6 ft in
