John Deere S680 Combine

John Deere S680 Combine Specs front
John Deere S680 Combine Specs front
John Deere S680 Combine Specs side
John Deere S680 Combine Specs side
John Deere S680 Combine Specs back
John Deere S680 Combine Specs back
Units

Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Engine Model

John Deere PowerTech PSS Engine

Power

473 hp

Power Boost Power

50 hp

Power Measured @

2200 rpm

Displacement

823.9 cu in

Operational

Operating Weight w/o Attachment

36114 lb

Fuel Capacity

305.2 gal

Feeding

Conveyor Width

55 in

Conveyor Length

68 in

Conveyor Speed

Threshing

Rotor Diameter

29.6 in

Rotor Length

123 in

Rotor Speed - Low

210 rpm

Rotor Speed - High

1000 rpm

Concave Area

1705.1 in2

Separating

Separator Type

rotary

Separating Area

2387.1 in2

Discharge Grate Area

1705.1 in2

Cleaning System

Total Cleaning Area

8137.6 in2

Cleaning Fan Speed - Low

620 rpm

Cleaning Fan Speed - High

1250 rpm

Grain Handling

Grain Tank Capacity

300.9 bu

Unloading Auger Length

22.5 ft in

Unloading Speed

3.3 bu/sec

Unloading Discharge Height

14.4 ft in
