John Deere R4044 Sprayer

John Deere R4044 Sprayer Specs front
John Deere R4044 Sprayer Specs front
John Deere R4044 Sprayer Specs side
John Deere R4044 Sprayer Specs side
John Deere R4044 Sprayer Specs extended
John Deere R4044 Sprayer Specs extended
Units

Specifications

Engine

Number of Cylinders

6

Fuel tank capacity

155 gal

Displacement

549.3 cu in

Emission level

Final Tier 4 (FT4)

Peak rated power

325.9 hp

Alternator

200 amp

Diesel exhaust fluid (DEF) tank capacity

7.8 gal

Drive Train

Drive Train Type

Hydrostatic

Drive

Full-time four-wheel drive (4WD)

Shifting

Electrohydraulic

Hydraulic reservoir capacity

25.9 gal

Spray speed range

0 to 40.2 km/h 0 to 25 mph

Transport speed, maximum

35 mph

Boom

Boom length options

27.4, 30.5, 36.6, or 40.2 m 90, 100, 120, or 132 ft

Automatic boom height

BoomTrac Pro™ - 5 sensor (optional)

Plumbing material

Stainless steel (polyethylene optional)

Ground height adjustment

50 to 245 cm 19.6 to 96.5 in.

Breakaway width

Stainless-steel boom - 3.3 m 10.8 ft Carbon fiber boom - 3.7 m 12.1 ft

Boom sections

13 sections with boom length - 40.2 m 132 ft 11 sections with boom length - 36.6 m 120 ft 9 sections with boom length - 30.5 m 100 ft 7 sections with boom length - 27.4 m 90 ft

Boom Material

Steel or carbon fiber

Solution System

Capacity

1000 gal

Tank material

Stainless steel

Rinse tank capacity

120 gal

Quick fill size

3 in

Automatic section control

John Deere Section Control (optional)

Solution system control

Automatic (optional) or manual

Fill location

Side fill, front fill (optional)

Chemical eductor

Stainless steel

Chemical eductor capacity (size)

8.5 gal

Flow meter size

2.1 in

Suction strainer

20 mesh

Pressure strainer

50 mesh

Boom Strainer

80 mesh

Chassis

Dry compatible

Yes - 5.7 m3 200 cu ft

Suspension

Dual-strut independent wheel air-ride suspension

Crop clearance with standard tires

152.4 cm 60 in.

Front tires

320/90 R46, 380/90 R46, or 420/80 R46

Rear tires

320/90 R46, 380/90 R46, or 420/80 R46

Flotation tires

520/85R38 or 620/70R38 (field installed only)

Hydraulic tread adjust

Standard

Wheel tread spacing

305 to 406 cm 120 to 160 in.

Wheel base

169.3 in

Turning radius

28.6 ft in

Parking brakes

Spring-engaged, hydraulic-disengaged wet disk pack

Ladder raise/lower

Automatic

Total weight with 100-ft boom

31438 lb

Total weight with 120-ft boom

31800 lb

Total weight with carbon fiber boom

36.6-m (120-ft) boom - 13,877.2 kg 30,594 lb 40.2-m (132-ft) boom - 13,915.3 kg 30,678 lb

Primary brakes

Hydrostatic

Total weight with 90-ft boom

31335 lb
