John Deere CT322 Multi Terrain Loader

John Deere CT322 Multi Terrain Loader Specs front
John Deere CT322 Multi Terrain Loader Specs front
John Deere CT322 Multi Terrain Loader Specs back
John Deere CT322 Multi Terrain Loader Specs back
John Deere CT322 Multi Terrain Loader Specs extended
John Deere CT322 Multi Terrain Loader Specs extended
Units

Dimensions

Dimensions

B

Width Over Tracks

5.96 ft in

C

Height to Top of Cab

6.41 ft in

E

Ground Clearance

9.61 in

G

Clearance at Max Lift and Dump

7.57 ft in

H

Reach at Max Lift and Dump

2.66 ft in

Undercarriage

I

Track Gauge

4.91 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2240

Engine Model

4024T

Gross Power

66 hp

Net Power

62 hp

Power Measured @

2800 rpm

Displacement

149 cu in

Aspiration

Turbocharged

Operational

Operating Weight

8305 lb

Fuel Capacity

18 gal

Operating Voltage

12 V

Alternator Supplied Amperage

70 amps

Max Speed - low range

5.5 mph

Max Speed - high range

8.5 mph

Loader

Breakout Force

6050 lb

Operating Load

2178.2 lb

Tipping Angle

6400 degrees

Undercarriage

Ground Pressure

5.1 psi

Number of Track Rollers per Side

4

Width of Track

12.6 in

Track Gauge

5 ft in

Hydraulic

Pump Flow

19 gal/min

Relief Valve Pressure

3450 psi

Dimensions

Width Over Tracks

6 ft in

Length with Bucket

10.5 ft in

Length with out Bucket

8.6 ft in

Height to Top of Cab

6.5 ft in

Ground Clearance

9.7 in

Clearance at Max Lift and Dump

7.6 ft in

Reach at Max Lift and Dump

2.7 ft in

Turning Radius from Center - inc bucket

78.9 in
