John Deere 9520RT Scraper Special 4WD Tractor
Units
Specifications
Engine
Engine Manufacturer
John Deere
Family
PowerTech? 13.5L
Cylinder Liners
Wet-sleeve
Fuel Tank Capacity
350gal
Displacement
824cu in
Aspiration
Dual Series Turbocharger w/fixed geometry first stage-variable geometry second stage - air-to-air aftercooling and cooled exhaust gas recirculation
Performance
Advertised Engine
520hp
Max Torque Rise
38%
Transmission
Standard Transmission; Forward/Reverse
e18? 18-speed PowerShift 40 kph (25 mph); 18F, 6R with Efficiency Manager?
Tires
Track Widths
30in
Hydraulic
Maximum Operating Pressure
2900psi
Remote Control Valves Available
4 Standard, 6 optional
Rated Flow @ One Scv
42gal/min
Hydraulic Type
Closed-center, pressure/flow compensated
Pump Rated Output
115gal/min
Final Drive
Final Drive Type
Outboard planetary
Brakes, Type And Control
Hydraulic power, wet disk, self adjusting on front and rear axle, plus secondary brake
Operator Station
Cab
\"Doors One-left handSeat Suspension System Air Suspension\"
