John Deere 9370R 4WD Tractor
Units
Dimensions
Dimensions
D
Wheelbase
149.89ft in
Turning Radius Without Brakes 1
18.21ft in
Specifications
Miscellaneous
Ballasting Restrictions
48700lb
Country Of Manufacture
Waterloo, Iowa, USA
Engine
Engine Manufacturer
John Deere
Cylinder Liners
Wet-sleeve
Fuel Tank Capacity
310gal
Displacement
548cu in
Power Take-Off(Pto)
Pto Speed
1000rpm
Pto Actuation
Electronic
Performance
Advertised Engine
370hp
Max Torque Rise
38%
Advertised Pto
335hp
Transmission
Standard Transmission; Forward/Reverse
e18? 18-speed PowerShift 40 kph (25 mph); 18F, 6R with Efficiency Manager?
Reverser
No
On-The-Go Shifting (Yes/No/Partial)
Yes
Tires
4wd
620/70R46 in. 167A8 R1W radial in dual wheel configuration
Hydraulic
Maximum Operating Pressure
2900psi
Rated Flow @ One Scv
42gal/min
Hitch Draft Control Load Sense Type
Electrohydraulic
Hitch Category (Sae Designation)
4N/Cat. 3, 4N/Cat. 4
Sensing Type
Electrohydraulic
Hydraulic System
Pump Flow Capacity
58.2gal/min
Hydraulic
Hydraulic Type
Closed-center
Pump Rated Output
115gal/min
Hitch Lift Cap
15000lb
Final Drive
Final Drive Type
Inboard planetary
Differential Controls
Full-locking electrohydraulic
Availability
Front and Rear Standard
Axle Type
Single reduction
Operator Station
Cab
Doors One - left handSeat Suspension System Standard: Air Optional: Active Seat
