John Deere 892D LC Long Front Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
45.92ft in
C
Shipping Height Of Unit
14.25ft in
I
Max Cutting Height
50.58ft in
J
Max Loading Height
43.42ft in
K
Max Reach Along Ground
60.5ft in
M
Max Digging Depth
45.83ft in
Boom/Stick Option (Hex) 1
Standard
Dimensions
E
Ground Clearance
1.58ft in
G
Height To Top Of Cab
9.83ft in
B
Width To Outside Of Tracks
11.08ft in
D
Length Of Track On Ground
13.17ft in
H
Tail Swing Radius
10.75ft in
Removal Counterweight Clearance
3.75ft in
Undercarriage
F
Track Gauge
8.5ft in
N
Shoe Size
31in
Max Travel Speed
2.5mph
Drawbar Pull
45410lb
Number Of Carrier Rollers Per Side
2
Number Of Shoes Per Side
50
Number Of Track Rollers Per Side
9
Ground Pressure
6psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6466A
Net Power
195hp
Gross Power
205hp
Power Measured @
2100rpm
Max Torque
827lb ft
Displacement
4667.7cu in
Aspiration
Turbocharged with aftercooler
Torque Measured @
1400rpm
Operational
Operating Weight
63875lb
Fuel Capacity
135gal
Cooling System Fluid Capacity
36gal
Hydraulic System Fluid Capacity
87gal
Engine Oil Capacity
25gal
Operating Voltage
24V
Swing Drive Fluid Capacity
11gal
Alternator Supplied Amperage
42amps
Hydraulic System Relief Valve Pressure
4050psi
Hydraulic Pump Flow Capacity
144.2gal/min
Swing Mechanism
Swing Speed
12rpm
Buckets
Reference Bucket Capacity
1yd3
