John Deere 850C LGP Crawler Tractor
Units
Dimensions
Dimensions
B
Width Over Tracks
13.06ft in
C
Height To Top Of Cab
10.34ft in
D
Length Of Track On Ground
10.09ft in
E
Ground Clearance
1.59ft in
Undercarriage
H
Standard Shoe Size
38in
Ground Pressure
4.6psi
Number Of Shoes Per Side
43
Number Of Track Rollers Per Side
7
Track Pitch
8in
Ground Contact Area
9196in2
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6081A
Gross Power
192hp
Net Power
185hp
Power Measured @
1800rpm
Max Torque
601lb ft
Displacement
494cu in
Torque Measured @
1300rpm
Aspiration
Altitude-compensating turbocharger; aftercooled
Operational
Operating Weight
42048lb
Fuel Capacity
92gal
Cooling System Fluid Capacity
9gal
Engine Oil Capacity
8.6gal
Hydraulic Fluid Capacity
21gal
Powertrain Fluid Capacity
27gal
Final Drives Fluid Capacity
3.3gal
Operating Voltage
24V
Alternator Supplied Amperage
45amps
Transmission
Transmission Type
Automatic, dual-path, hydrostatic drive
Max Speed - Forward
6.8mph
Max Speed - Reverse
6.8mph
Hydraulic System
Pump Type
Gear
Relief Valve Pressure
2250psi
Pump Flow Capacity
44gal/min
Standard Blade
Width
13.1ft in
Height
43.8in
Capacity
7.2yd3
Blade Angle (Both Directions)
25degrees
Cutting Depth
16.9in
