John Deere 84 Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
11.5ft in
Breakout Force
9040lb
Bucket Capacity - Heaped
1yd3
Bucket Capacity - Struck
0.9yd3
Bucket Width
6.83ft in
Dimensions
E
Ground Clearance
1.02ft in
A
Length With Bucket On Ground
15.23ft in
B
Width Over Tires
6.58ft in
C
Height To Top Of Cab
9.5ft in
D
Wheelbase
7.22ft in
F
Hinge Pin - Max Height
9.91ft in
Specifications
Engine
Engine Make
2348
Engine Model
4TN100
Net Power
52hp
Gross Power
55hp
Max Torque
174lb ft
Displacement
211cu in
Aspiration
Natural
Operational
Operating Weight
11246lb
Fuel Capacity
15.3gal
Hydraulic System Fluid Capacity
18.5gal
Engine Oil Fluid Capacity
3.4gal
Cooling System Fluid Capacity
5.3gal
Transmission Fluid Capacity
6.1gal
Front Axle/Diff Fluid Capacity
2.6gal
Rear Axle/Diff Fluid Capacity
2.6gal
Static Tipping Weight
8930lb
Turning Radius
12.5ft in
Operating Voltage
24V
Alternator Supplied Amperage
25amps
Rear Axle Oscillation
16degrees
Tire Size
17.5/65-20
Transmission
Transmission Type
Powershiift
Number Of Forward Gears
3
Number Of Reverse Gears
1
Max Speed - Forward
17.7mph
Max Speed - Reverse
7.1mph
Hydraulic System
Relief Valve Setting
2500psi
Pump Flow Capacity
21.1gal/min
Raise Time
5.4sec
Dump Time
1sec
Lower Time
3.5sec
Pump Type
Gear
