John Deere 8345RT MFWD Tractor

John Deere 8345RT MFWD Tractor Specs front
John Deere 8345RT MFWD Tractor Specs front
John Deere 8345RT MFWD Tractor Specs side
John Deere 8345RT MFWD Tractor Specs side
John Deere 8345RT MFWD Tractor Specs back
John Deere 8345RT MFWD Tractor Specs back
Units

Dimensions

Dimensions

D

Wheelbase

99 ft in


Specifications

Engine

Number of Cylinders

6

Engine Manufacturer

John Deere

Cylinder liners

Wet

Fuel tank capacity

200 gal

Aspiration

Variable geometry turbocharger with air-to-air aftercooling and cooled exhaust gas recirculation

Displacement

549 cu in

Power Take-Off(PTO)

Standard

\"45 mm 1.75 in. 20 spline, 1000 rpm\"

PTO Actuation

Electro-hydraulic

PTO Speeds @ Engine rpm

At 2000 rpm: 1000 rpm

Performance

Advertised PTO

275 hp

Advertised Engine

345 hp

Max Unballast Drwbr hp (kW) @ Eng rpm

266.8 hp

Maximum Torque (PTO)

1039 lb ft

Maximum Torque Rise % (PTO) @ Eng rpm

Official PTO hp (kW) @ Rated rpm hp (kw)

\"Maximum @ Eng rpm At 1800 rpm: 237.77 kW 318.85 hp At 2096 rpm: 207.93 kW 278.85 hp\"

Transmission

Clutch, wet/dry

Wet

Creeper

IVT

Reverser

Right hand with IVT

On-the-Go Shifting (Yes/No/Partial)

Yes

Tires

Track widths

\"Standard: 635 mm 25 in. Optional: 406 mm 16 in. 457 mm 18 in. 610 in. 24 762 mm 30 in.\"

Hydraulic

Maximum operating pressure

2900 psi

Remote control valves available

\"Four standard Three or five optional\"

Rated Flow @ One SCV

35 gal/min

Hitch Draft Control Load Sense Type

Electronic

Sensing type

Electro-hydraulic

Pump rated output

\"Standard 166.6 L/min 44 gpmOptional 227.1 L/min 60 gpm\"

Hydraulic Type

Closed-center, pressure/flow compensated

Final Drive

Final Drive Type

Inboard planetary

Axle Type

Bar

Brakes, Type and Control

Hydraulic wet disc

Operator Station

Rollover protective structure

\"Rigid - Foldable - Telescopic Rigid (cab)Platform - Flat/Straddle FlatGearshift Location - Console/Floor CommandArm\"

Cab

\"Doors One on left sidePlatform - Flat/Straddle FlatdB(A) Rating 69.8 dBASeat Suspension System Air\"

Dimensions

Wheelbase

99 ft in

Unballasted Operating Weight

34460 lb

Wheel Tread, Min. to Max. in. (mm)

\"Standard: 1829-3048 mm 72-120 in. Optional: 2845-4064 mm 112-160 in.\"
