John Deere 75C Midi Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
19.26ft in
C
Shipping Height Of Unit
8.83ft in
I
Max Cutting Height
23.66ft in
J
Max Loading Height
16.8ft in
K
Max Reach Along Ground
20.54ft in
L
Max Vertical Wall Digging Depth
12.05ft in
M
Max Digging Depth
13.49ft in
Boom/Stick Option (Hex) 1
5\'4\" (1620mm) stick
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
19.53ft in
C
Shipping Height Of Unit
9.29ft in
I
Max Cutting Height
24.97ft in
J
Max Loading Height
18.08ft in
K
Max Reach Along Ground
22.18ft in
M
Max Digging Depth
15.13ft in
L
Max Vertical Wall Digging Depth
13.82ft in
Boom/Stick Option (Hex) 2
6\'11\" (2120mm) stick
Dimensions
B
Width To Outside Of Tracks
7.62ft in
D
Length Of Track On Ground
7.52ft in
E
Ground Clearance
1.19ft in
G
Height To Top Of Cab
8.83ft in
H
Tail Swing Radius
3.97ft in
Removal Counterweight Clearance
2.5ft in
Undercarriage
N
Shoe Size
23.63in
F
Track Gauge
6.14ft in
Drawbar Pull
12350lb
Number Of Carrier Rollers Per Side
1
Number Of Shoes Per Side
40
Number Of Track Rollers Per Side
5
Ground Pressure
3.53psi
Max Travel Speed
3.1mph
Specifications
Engine
Number Of Cylinders
4
Engine Make
2353
Engine Model
CC-4JG1
Net Power
54hp
Power Measured @
2100rpm
Displacement
187cu in
Max Torque
142lb ft
Torque Measured @
1700rpm
Aspiration
Natural
Operational
Operating Weight
17714lb
Fuel Capacity
31.8gal
Cooling System Fluid Capacity
1.6gal
Operating Voltage
24V
Hydraulic System Fluid Capacity
26.5gal
Engine Oil Capacity
2.7gal
Alternator Supplied Amperage
30amps
Hydraulic System Relief Valve Pressure
4550psi
Hydraulic Pump Flow Capacity
36.6gal/min
Swing Mechanism
Swing Torque
10200lb ft
Swing Speed
11rpm
Buckets
Reference Bucket Capacity
0.4yd3
Minimum Bucket Capacity
0.3yd3
Maximum Bucket Capacity
0.8yd3
