John Deere 755B Crawler Loader

Crawler Loader
Crawler Loader
Crawler Loader
Crawler Loader
Crawler Loader
Crawler Loader
Units

Dimensions

Dimensions

A

Length With Bucket On Ground

18.51ft in

E

Ground Clearance

15.3ft in

C

Height To Top Of Cab

10.31ft in

G

Clearance At Full Height And Dump

9.34ft in

H

Reach At Dump Height

3.92ft in

F

Length To Front Of Track

18.51ft in

Undercarriage

I

Track Gauge

66in

D

Length Of Track On Ground

7.8ft in

Number Of Shoes Per Side

36

Ground Contact Area

3173in2

Track Shoe Width

17in

Number Of Track Rollers Per Side

1

Ground Pressure

11.4psi


Specifications

Engine

Number Of Cylinders

6

Engine Make

2240

Engine Model

6068T

Net Power

140hp

Power Measured @

2100rpm

Max Torque

420lb ft

Aspiration

Turbocharged

Torque Measured @

1300rpm

Displacement

414cu in

Operational

Operating Weight

36150lb

Fuel Capacity

73gal

Cooling System Fluid Capacity

7gal

Engine Oil Capacity

5gal

Final Drive Fluid Capacity - Each

3.5gal

Hydraulic System Fluid Capacity

37gal

Static Tipping Load

25340lb

Breakout Force - Std Bucket

27500lb

Bucket Capacity - Struck

1.9yd3

Operating Voltage

24V

Alternator Supplied Amperage

40amps

Max Speed

6.7mph

Hydraulic

Pump Type

Gear

Pump Flow Capacity

54gal/min

Relief Valve Pressure

2500psi

Raise Time

5.9sec

Dump Time

1.3sec

Lower Time

3.3sec
