John Deere 750C WT Crawler Tractor

John Deere 750C WT Crawler Tractor Specs front
John Deere 750C WT Crawler Tractor Specs front
John Deere 750C WT Crawler Tractor Specs side
John Deere 750C WT Crawler Tractor Specs side
John Deere 750C WT Crawler Tractor Specs back
John Deere 750C WT Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

16.26 ft in

B

Width Over Tracks

8 ft in

C

Height to Top of Cab

10.06 ft in

D

Length of Track on Ground

8.51 ft in

E

Ground Clearance

1.22 ft in

Undercarriage

G

Track Gauge

6.17 ft in

H

Standard Shoe Size

34 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Engine Model

6068T

Gross Power

148 hp

Net Power

140 hp

Power Measured @

2100 rpm

Max Torque

420 lb ft

Displacement

414 cu in

Torque Measured @

1300 rpm

Aspiration

Altitude-compensating turbocharger

Operational

Operating Weight

33324 lb

Fuel Capacity

74 gal

Cooling System Fluid Capacity

7 gal

Engine Oil Capacity

5.1 gal

Hydraulic Fluid Capacity

18 gal

Final Drives Fluid Capacity

6.3 gal

Operating Voltage

24 V

Alternator Supplied Amperage

45 amps

Transmission

Transmission Type

Hydrostatic

Max Speed - Forward

6.8 mph

Max Speed - Reverse

6.8 mph

Undercarriage

Ground Pressure

4.9 psi

Ground Contact Area

6936 in2

Standard Shoe Size

34 in

Number of Shoes per Side

40

Number of Track Rollers per Side

7

Track Pitch

7.5 in

Track Gauge

6.2 ft in

Hydraulic System

Pump type

Gear

Relief Valve Pressure

2000 psi

Pump Flow Capacity

38 gal/min

Standard Blade

Width

11.1 ft in

Height

38.4 in

Capacity

3.3 yd3

Cutting Depth

20.2 in

Dimensions

Length w/ Blade

16.3 ft in

Width Over Tracks

8 ft in

Height to Top of Cab

10.1 ft in

Length of Track on Ground

8.6 ft in

Ground Clearance

1.3 ft in
