John Deere 750B LT Crawler Tractor
Units
Dimensions
Dimensions
C
Height To Top Of Cab
10.22ft in
D
Length Of Track On Ground
8.42ft in
E
Ground Clearance
1.17ft in
Undercarriage
H
Standard Shoe Size
22in
Ground Pressure
7.1psi
Ground Contact Area
4444in2
Number Of Shoes Per Side
43
Number Of Track Rollers Per Side
2
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6068T
Gross Power
148hp
Net Power
140hp
Power Measured @
2100rpm
Max Torque
420lb ft
Displacement
414cu in
Torque Measured @
1300rpm
Aspiration
Turbocharger
Operational
Operating Weight
31530lb
Fuel Capacity
73gal
Cooling System Fluid Capacity
7gal
Hydraulic Fluid Capacity
33gal
Powertrain Fluid Capacity
33gal
Final Drives Fluid Capacity
8.5gal
Operating Voltage
24V
Alternator Supplied Amperage
40amps
Transmission
Transmission Type
Automatic, dual-path, hydrostatic drive
Max Speed - Forward
6.5mph
Max Speed - Reverse
6.5mph
Hydraulic System
Pump Type
Vane
Relief Valve Pressure
2000psi
Pump Flow Capacity
38gal/min
Standard Blade
Height
42.2in
Capacity
3yd3
Cutting Depth
20.2in
